Technical Parameter :
|
NO. |
parameter |
parameter |
option |
|
|
1 |
Working area |
X |
1200mm |
|
|
Y |
2400mm |
|
||
|
Z |
900mm |
|
||
|
C |
210℃(±130℃) |
|
||
|
A |
210℃(±105℃) |
|
||
|
2 |
Table size |
1250x2500mm |
|
|
|
3 |
Accuracy |
Process accuracy |
±0.04mm |
|
|
Reposition accuracy |
±0.05mm |
|
||
|
4 |
Structure |
Table |
Whole cast steel |
|
|
X,Y,Z structure |
X Y rack pinion, Z ball screw |
|
||
|
5 |
Speed |
Max speed |
≥40000mm/min |
|
|
Working speed |
≥30000mm/min |
|
||
|
6 |
Spindle |
Power |
10.0KW |
|
|
Speed |
100-24000r/min |
|
||
|
7 |
Work mode |
|
Servo |
|
|
8 |
Work voltage |
|
AC380V/50Hz |
|
|
9 |
Command |
|
G mode ,F/S |
|
|
10 |
System |
|
OSAI |
|
|
11 |
NET Weight |
|
12000kg |
Applicable industries of 5 axis cnc machines :
Mold industry:
various large metalloid molds, especially suitable for automotive foam molds, wooden ship models, wooden aviation models, wooden rail molds, wooden train molds.
Instrument industry:
3-d surface engraving and shape cutting of large-scale instruments.
