Place of Origin:
China
Brand Name:
AOKE
Certification:
CE, SGS, ISO
Model Number:
DCZ50
Contact Us
Gasket Production Sample Blade Cutting Machine Sign Making Cutter Features:
1.It can cut many different materials (Non-Asbestos Fibre, flexible graphite, Inorganic fibre, modified PTFE styles)
2.It can fold corrugated paper, card paper and offset board into perfect folding line.
3.It can half cut ,whole cut,crease and dotted line.
4.Using laser lamp improve location precision
5.using for sample maker or small batch of production.
Graphite Gasket CNC Cutting Table Short Run Production Making Machine Parameters:
|
TYPE |
DCP2516 |
DCP1713 |
DCP1310 |
|
Effective cutting area |
2500*1600mm |
1700*1300mm |
1300*1000mm |
|
Configuration |
Oscillating blade. pen. creasing wheel. |
||
|
Function |
It is used in carton& paper box packaging factory. it can cut and crease 15mm corrugated paper. |
||
|
Max speed |
1000mm/s |
||
|
Smallest cutting diameter |
6mm |
||
|
Maximum cutting thickness |
15mm |
||
|
Control line and driver |
Servo |
||
|
Precision |
≤0.1mm |
||
|
vacuum |
5.5kw |
||
|
Data form |
HPGL |
||
|
Voltage |
220v±10% 50Hz |
||
|
Data port |
PCI port |
||
|
Data Transmission speed |
10MB/S |
||
|
Using dimension(mm |
315*2380*1150 |
2370*2200*1150 |
1960*1890*1150 |
|
Input cushion area |
32MB |
||
