Place of Origin:
Zhejiang China
Brand Name:
HAICHEN
Certification:
ISO9001:2000, CE
Model Number:
HCW400JD
Contact Us
HCW400JD PE Home Plastic Injection Molding Machine
Quick Detail:
HCW400JD home appliance injection molding machine is for normal type plastic material injection, e.g. PC, PP, PE, etc. This machine is mainly used to produce plastic bucket.
The machine is with servo motor to save power, compare with standard machine, according to specific products, the servo motor machine can save power 30% to 70%.
Applications:
HCW400JD injection molding machine is for small industrial parts, such as 5L plastic bucket, fork and knife, material PC, PP, PE, etc., suitable plastic products weight 10g-655g, mold cavity can be: 1 Cavity, 2 Cavities, 3 Cavities, 4 Cavities, 6 Cavities, 8 Cavities, 10 Cavities, 12 Cavities,16 Cavities, 24 Cavities
Description:
HCW400JD home appliance injection molding machine is the type of fully-automatic machine, being provided with high efficiency, high reliability, high speed, low noise, low power consumption and other advantages
Machine main components adopt world famous brand, e.g.:
• PLC: TECHMATION CONTROLLER(Taiwan)
• AC Contactor: SIEMENS(Germany)
• Travel switch: SCHNEIDER(FRANCE),
• Transducer: NOVOTK (Germany)
• Proportional Valve: HNC(TAIWAN)
• Oil pump: VICKERS(USA)
• Directional Valve: VICKERS(USA)
• High-pressure pipe line: GOOD YEAR (USA)
CLAMING UNIT
-Double-toogle five-joint clamping machinery
-High rigidity mould platen with enlarged space between tie bar
-Platen with both T-slot and mould tapped
-Movable platen supported by the adjustable slide system which improves platen parallelism and life time of tie bar and mould
-Optimized lubrication system ensuring precision clamping and prolonging the life time of the clamping
-Special design of hydraulic oil cylinder for High speed action
-High precision auto-clamping function according to the clamping force settled
Servo motor configurations:
• PLC: Taiwan TECHMATION controller
• Oil pump: Germany ECKERLE
• Servomotor: Italy PHASE
