Place of Origin:
Shenzhen,China
Brand Name:
Q-Color
Certification:
CCC CE EMC FCC RoHS TUV
Model Number:
ODC-6S
Contact Us
Aluminum Die - Cast P6mm Energy Saving SMD Rental LED Screen for Banquet meeting
Die-casting Rental LED Screen Main Features:
1.Various choices with tighten pitch for outdoor :P6.p8.p10 outdoor SMD technology available from 5000-6500nits to match outdoor application ;
2.Precisely cabinet :Aluminum die-casting cabinet with CNC machined aligning corner, ensure no gaps between cabinets ;
3.Wide view angle :With 120/120 degree view angle ,bring a wonderful image ;
4.High refresh rate : 1920Hz refresh rate and 5000:1 contrast ratio ensure the image color more vivid ;
5.Fanless design :Professional fanless design to make sure the noise less than 25db ;
6.Integrated and visual operation : All the controllable devices such as display , video processor , matrix switching equipment ,camera , multi-function equipment etc could whole package or optional .
7. Reliable :working life-span with 100000hours ,help customers earn more profits ;
Main Speicification:
| Item | Technical Parameters | |||
| Module | Model | ODC-6S | ODC-8S | ODC-10S |
| Pixel Pitch | 6mm | 8mm | 10mm | |
| Pixel Density (dot/m2) | 27,777 | 15,625 | 10,000 | |
| LED Configuration | 1R1G1B | 1R1G1B | 1R1G1B | |
| LED Package | SMD3535 | SMD3535 | SMD3535 | |
| Module Size(mmxmm) | 288x288 | 288x288 | 320x320 | |
| Module Resolution | 48x48 | 36x36 | 32x32 | |
| Others | Brightness(cd/m2) | ≥5,500 | ≥5,500 | ≥5,500 |
| Driving Mode | 1/8 scan | 1/4 scan | 1/4 scan | |
| Grey Level | >14 bit | |||
| Refresh Rate | > 960 hertzs | |||
| Cabinet Resolution(wxh) | 96x96 | 72x72 | 64x64 | |
| Max. Power(w/m2) | < 1,100 | < 960 | < 960 | |
| Avg Power(w/m2) | 360~550 | 320~480 | 320~480 | |
| Cabinet Size(mmxmm) | 576*576 | 576*576 | 640*640 | |
| Viewing Angle | Horizontally 120°; Vertically 120° | |||
| Ingress Protection | IP65 | |||
Cabinet view:
Our services:
1.Could provide LED display project support and do investigation in local places since our customers start the LED display project budget.
2.Customized LED screen software and hardware products will be provided base on customers’ requirements.
3.Provide LED screen technical training (factory or on-site) for different customers.
4.Drawings like steel structure drawing, connection drawing, etc. can be provided after the order.
5.Timely online services are provided whenever there is software operational problems and we’ll solve problems as soon as possible in working with our customers.
6.USA and Netherlands Netherlands exhibition show:ISA,Infocomm,ISE etc.
Workshop and Office
1.What’s the life time of LED screens?
The life time of the LED screens is basically over 100,000 hours, but it depends how the screen is taken care of. When LED Screens’ life time up to 100,000 hours, the brightness of the LED lamps will be about 50% off compared to the original ones.
2.How to protect power supply?
Electrical peaks can put more force on the electrical components which decreases the working time. So, it is wise to install a protection (voltage stabilizer) that can control the peaks.
3.How to maintenance LED screens?
The soldering of the LED chips can dry out and break which requires changing components such as LED modules or receiving cards. We will supply free spare modules.
4.What is the return policy?
If the modules died exceed 1%, we will resend you the new one.
5.In order to offer you a suitable solution, please state general info about your project.
1. Pixel pitch and view distance you need.
2. Dimension
3. Location of installation.
4. Purpose. (What are you going to do with the LED display)
5. Rental or fixed installation.
Packaging: Plywood or Flight case
Parts of Domestic and Overseas Projects:
Could you just please let us know your detailed project information?
1. The pixel pitch you require or the viewing distance(the distance between the LED displays and the audience)?
2. for permanent installation or rental application?
3. the detailed dimensions of the LED screen, width and height?
Q-Color would be very glad to provide you the most professional solution with good price upon receipt of your confirmation
