Place of Origin:
China
Brand Name:
INMIND
Certification:
SGS Factory Certificater
Model Number:
Ball-Nose Long Neck type 0.5mm to 4mm
Contact Us
Long Neck 2 Flute Solid Carbide End Mills By 5 AXIS CNC Grinder , Standard Type
Quick Detail:
0.5-0.6um Ultra-Fine grain size solid carbide rod
TIALN Coating (Black),TiSiAlN(Copper)
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC55
1 piece packing.
Long Neck 2 Flute
Description:
Ultra-Fine Grain Szie 0.5-0.6um, Wc carbide rod with high tenacity,with high quality TiAlN coating,getting long tool life,from roughing to finishing processing,reduce time of changing cutters,improving efficency of machine,saving time of making moulds.Suggest to process iron and steel upto HRC55,Middle-High speed.
Carbide Rod:Wc:88%,Co:12%,TRS:4000N/mm2, Grain Size:0.5-0.6um
Applications:
Fit for milling quenching and tempered steel.stainless steel.nickel alloy and Titanium alloy,Cast iron,enhanced composited material with fiberglass,Also fit for milling copper.
Specifications:
|
Order No |
Cutting |
Neck Dia |
Flute Length |
Effective Length |
Shank |
A.O.L |
|
d |
N |
l |
E |
D |
L |
|
|
ULNB 05022 |
R0.25 |
0.45 |
0.75 |
2 |
4 |
50 |
|
ULNB 05042 |
R0.25 |
0.45 |
0.75 |
4 |
4 |
50 |
|
ULNB 05062 |
R0.25 |
0.45 |
0.75 |
6 |
4 |
50 |
|
ULNB 05082 |
R0.25 |
0.45 |
0.75 |
8 |
4 |
50 |
|
ULNB 06022 |
R0.3 |
0.55 |
0.9 |
2 |
4 |
50 |
|
ULNB 06042 |
R0.3 |
0.55 |
0.9 |
4 |
4 |
50 |
|
ULNB 06062 |
R0.3 |
0.55 |
0.9 |
6 |
4 |
50 |
|
ULNB 06082 |
R0.3 |
0.55 |
0.9 |
8 |
4 |
50 |
|
ULNB 08022 |
R0.4 |
0.75 |
1.2 |
2 |
4 |
50 |
|
ULNB 08042 |
R0.4 |
0.75 |
1.2 |
4 |
4 |
50 |
|
ULNB 08062 |
R0.4 |
0.75 |
1.2 |
6 |
4 |
50 |
|
ULNB 08082 |
R0.4 |
0.75 |
1.2 |
8 |
4 |
50 |
|
ULNB 10062 |
R0.5 |
0.95 |
1.5 |
6 |
4 |
50 |
|
ULNB 10082 |
R0.5 |
0.95 |
1.5 |
8 |
4 |
50 |
|
ULNB 10102 |
R0.5 |
0.95 |
1.5 |
10 |
4 |
50 |
|
ULNB 10122 |
R0.5 |
0.95 |
1.5 |
12 |
4 |
50 |
|
ULNB 15082 |
R0.75 |
1.45 |
2 |
8 |
4 |
50 |
|
ULNB 15102 |
R0.75 |
1.45 |
2 |
10 |
4 |
50 |
|
ULNB 15122 |
R0.75 |
1.45 |
2 |
12 |
4 |
50 |
|
ULNB 15166 |
R0.75 |
1.45 |
2 |
16 |
4 |
50 |
|
ULNB 15202 |
R0.75 |
1.45 |
2 |
20 |
4 |
50 |
|
|
|
|
|
|
|
|
|
ULNB 20082 |
R1.0 |
1.92 |
3 |
8 |
4 |
50 |
|
ULNB 20102 |
R1.0 |
1.92 |
3 |
10 |
4 |
50 |
|
ULNB 20122 |
R1.0 |
1.92 |
3 |
12 |
4 |
50 |
|
ULNB 20162 |
R1.0 |
1.92 |
3 |
16 |
4 |
50 |
|
ULNB 20202 |
R1.0 |
1.92 |
3 |
20 |
4 |
50 |
|
ULNB 30082 |
R1.5 |
2.9 |
4.5 |
8 |
6 |
50 |
|
ULNB 30102 |
R1.5 |
2.9 |
4.5 |
10 |
6 |
50 |
|
ULNB 30122 |
R1.5 |
2.9 |
4.5 |
12 |
6 |
50 |
|
ULNB 30162 |
R1.5 |
2.9 |
4.5 |
16 |
6 |
50 |
|
ULNB 30202 |
R1.5 |
2.9 |
4.5 |
20 |
6 |
60 |
|
ULNB 30252 |
R1.5 |
2.9 |
4.5 |
25 |
6 |
60 |
|
ULNB 40122 |
R2 |
3.9 |
8 |
12 |
6 |
60 |
|
ULNB 40162 |
R2 |
3.9 |
8 |
16 |
6 |
60 |
|
ULNB 40202 |
R2 |
3.9 |
8 |
20 |
6 |
60 |
|
ULNB 40252 |
R2 |
3.9 |
8 |
25 |
6 |
75 |
|
ULNB 40302 |
R2 |
3.9 |
8 |
30 |
6 |
75 |
Competitive Advantage:
Good and Stable Quality.
New Coating TiSiAlN Improve the performance in high hardness material and stainless steel.
Competitive price.
Help the agent to get the get more large market in the quality products.
