Place of Origin:
China
Brand Name:
RUNLAI
Certification:
ISO9001:2008
Model Number:
RL
Contact Us
· Place of Origin: Jiangsu, China (Mainland)
· Model Number: GDL125-40-12Z/7.5
· Application: Milling
· Drive: Inverter
· Operating Speed: 12000rpm
|
Packaging Details: |
wooden/cartons |
|
Delivery Detail: |
a month
GDL series of electric spindle is developed by automatic tool change electric spindle, which use four motor drives, BT40 shank. It uses muli-layered defense of the double seal structure plus air sealing structure, when the fluid can effectively prevent, keep the prolonged use of electric spindle. It uses GMN imported bearings, monitor grease to ensure performance. Tool changing structureoptimized design and manufacture. To ensure reliable and stable signal and tool change action.
|
Spindle Type: GDL125-40-12Z/7.5
Power: 7.5Kw
Speed: 12000rpm
Voltage: 380V
Current: 16.5A
Frequency: 600Hz
Joint of nose: BT40
Lub: grease
Cool: by water
Bearings type: 2XSM6011C/P4 2X7008C/P4
Weight:35kg
