Place of Origin:
China
Brand Name:
Thermostat Bimetallic Strip
Certification:
ISO 9001 and RoHS
Model Number:
5J1480, Kanthal 135, ТБ 1423
Contact Us
5J1480 / Kanthal 135 / ТБ 1423 Precision Alloy Precision CNC Machining Services
Name: 5J1480/ Kanthal 135/ ТБ 1423
Application: The material is mainly in automatic control devices and instrumentation (eg: exhaust thermometers, thermostats, voltage regulators, temperature relay, automatic protection switching, diaphragm meters, etc.) make temperature control, temperature compensation, current limit, temperature indicator and other heat-sensitive components.
Feature: The basic characteristics of Thermostat Bimetallic is bending deformation with temperature changes, resulting in a certain moment.
Thermostat Bimetallic Strip expansion coefficient is different from the two or more layers of metal or alloy along the entire contact surface firmly bonded, having a temperature-dependent shape change occurs thermosensitive functional composites. Wherein the higher expansion coefficient of the active layer is a layer called a low coefficient of expansion of the layer is named passive layer.
|
Grade |
5J1480 |
|
High expansion layer |
Ni22Cr3 |
|
Low expansion layer |
Ni36 |
Description:
Chemical composition(%)
|
Grade |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Cu |
Fe |
|
Ni36 |
≤0.05 |
≤0.3 |
≤0.6 |
≤0.02 |
≤0.02 |
35~37 |
- |
- |
Bal. |
|
Grade |
C |
Si |
Mn |
P |
S |
Ni |
Cr |
Cu |
Fe |
|
Ni22Cr3 |
≤0.35 |
0.15~0.3 |
0.3~0.6 |
≤0.02 |
≤0.02 |
21~23 |
2.0~4.0 |
- |
Bal. |
Physical properties
Specifications
|
Grade |
5J1480/ Kanthal 135 |
|
Thickness |
0.1~3mm |
|
Width |
2~200mm |
|
Weight of coil |
2-50 kgs |
|
Condition |
Bright |
